Masala Pulverizer

The Masala Pulverizer is designed for efficient and uniform grinding of various spices such as turmeric, chili, coriander, cumin, and other dry masalas. Its advanced grinding system delivers fine and consistent powder while ensuring smooth and efficient operation.

Built with durable materials, the machine offers reliable performance, easy operation, low maintenance, and long-lasting durability, making it suitable for commercial and industrial masala processing.

5 HP 7.5 HP 10 HP 20 HP
Clarnigo Machines
Micro Pulverizer Turmeric-Haldi
Micro Pulverizer Dry Chilli (Sukhi Mirchi)
Micro Pulverizer Garam Masala
Micro Pulverizer Coriander (Dhaniya)
Micro Pulverizer Coffee
Micro Pulverizer Herbs (Jadi-Butiya)
Micro Pulverizer Black Pepper (Kali Mirchi)
Micro Pulverizer asafoetida-Hing
Technical details

Specifications

5HP 7.5HP 10HP 20HP
MODEL NUMBER CGMC00503 CGMC007003 CGMC001003 CGPMC002003
HOPPER CAPACITY 25 - 30KG 50 - 55KG 60 - 70KG 90 - 100KG
GRINDING CAPACITY 40 - 50KG 60 - 80KG 70 - 100KG 150 - 200KG
POWER SOURCE ELECTRIC ELECTRIC ELECTRIC ELECTRIC
VOLTAGE (V) 415 415 415 415
CURRENT (A) 7.5 11 15 26
POWER CONSUMPTION 5KWH 7.5KWH 9.5KWH 18KWH
MOTOR SPEED 3600 3600 3600 3600
MATERIAL MS+SS MS+SS MS+SS MS+SS
COATING POWDER COATING POWDER COATING POWDER COATING POWDER COATING
NUMBER OF MOTOR 3 3 3 3
TOTAL HP 6.5HP 10HP 12.5HP 22.5HP
BEATERS 3 3 3 3
CUTTERS 3 3 3 3
CHAMBER 3 CHAMBER 3 CHAMBER 3 CHAMBER 3 CHAMBER
HEIGHT 46 48 50.5 59
WIDTH 22 25.5 27.5 29
LENGTH 59 62.5 63.5 75
CYCLONE (H X W X L) 83 X 23 X 23 88 X 27.5 X 27.5 88 X 27.5 X 27.5 88 X 27.5 X 27.5
